CopperSound Pedals Gravity Bomb Fusion Series Black Plate

Gravity Bomb Fusion Series Black Plate

£179.00

Discontinued

Highlights

• Boost pedal with selectable diode clipping and hi cut filtering
• Up to 20dB clean boost with optional silicon and germanium-style clipping
• Highly responsive, touch-sensitive feel with excellent note definition
• Three-position clipping and hi cut toggles plus precise Boost control
• Burr Brown op amp driven analogue boost circuit
• Hand built, wired and soldered construction
• Rugged all metal enclosure for reliable pedalboard use
• Striking dual tone hazard-inspired graphics
• LED power indicator for clear on/off status
• Mechanical true bypass switching
• Top mounted jack sockets for neat pedalboard layout
• Fully analogue signal path
• Limited lifetime manufacturer warranty

Description

The CopperSound Pedals Gravity Bomb Fusion Series is a versatile clean boost and clipping pedal designed to strengthen the core of any guitar or bass rig. Part of the Fusion Series, it delivers up to 20dB of boost, making it equally effective as an always-on tone enhancer, a solo lift, or a front-end driver for pushing valve amps and other pedals. Its flexible clipping and filtering options allow it to cover transparent boost duties, light drive textures and more assertive edge, fitting comfortably into styles ranging from blues and classic rock to alternative and heavier sounds.

At its heart is an audiophile grade Burr Brown op amp that keeps the boosted signal clear, dynamic and articulate. With clipping disengaged, the CopperSound Pedals Gravity Bomb Fusion Series provides a full-range, clean lift that enhances headroom and clarity without masking the character of the guitar, bass or amplifier. Engaging one of the diode options introduces harmonically rich saturation, with distinct flavours available for players who want a touch of grit or a more textured response. When stacked with overdrive or fuzz pedals, it adds sustain, focus and harmonic complexity while retaining definition.

The CopperSound Pedals Gravity Bomb Fusion Series feels immediate and responsive under the fingers. Pick attack translates naturally, chords remain open and detailed, and single notes retain body and presence. Running at 9V delivers punch and energy, while 18V operation increases headroom and dynamic range, making it particularly effective for players who use higher output pickups or want maximum clarity from a boosted clean tone.

Control is straightforward but powerful. A dedicated Boost control sets the overall output level, offering everything from subtle enhancement to a substantial volume lift. A three-position clipping toggle selects between BAT41 silicon diode clipping, no clipping for pure clean boost, or 1n60P diode clipping for an alternative character. A separate three-position hi cut toggle shapes the top end, with 3.3K and 1.5K cut options to smooth brightness or add warmth, or a flat setting for full frequency response. Together, these controls provide four core tonal directions with further fine adjustment via the Boost knob.

The CopperSound Pedals Gravity Bomb Fusion Series uses high quality components throughout, centred around the Burr Brown op amp and carefully selected diodes for consistent performance and low noise. The analogue circuit is designed for reliability and stable operation whether used as a subtle tone sweetener or as a more aggressive signal driver.

Housed in a rugged all metal enclosure, the CopperSound Pedals Gravity Bomb Fusion Series is built for regular stage and studio use. Its distinctive dual tone hazard-inspired graphics stand out clearly on a crowded board, while remaining easy to read under stage lighting. A bright LED indicator provides clear visual confirmation of on and off status at a glance.

Mechanical true bypass switching ensures that when disengaged, the CopperSound Pedals Gravity Bomb Fusion Series preserves the integrity of the original signal. Top mounted jack sockets help maximise pedalboard space and simplify cable management, particularly in tighter setups.

Backed by a limited lifetime warranty, the CopperSound Pedals Gravity Bomb Fusion Series offers dependable performance and flexible tonal shaping in a compact, road-ready format. For players seeking a high quality clean boost with selectable clipping and practical tone control, it provides a thoughtful balance of clarity, character and control.

Controls

• FOOTSWITCH: Engages and disengages the pedal via mechanical true bypass
• BOOST: Sets output from subtle lift to full 20dB boost
• LEFT TOGGLE: Selects BAT41 clipping, no clipping, or 1n60P clipping
• RIGHT TOGGLE: Chooses 3.3K cut, flat, or 1.5K hi cut response
• BYPASS SWITCH: Engages or disengages true bypass operation

Components and Technical Specification

• Analogue boost circuit with selectable diode clipping
• Burr Brown op amp for low noise, high clarity performance
• BAT41 silicon diode for defined, tighter clipping character
• 1n60P diode for alternative clipping texture
• Three position hi cut filter for top end control
• Mechanical true bypass switching
• All metal enclosure for durability
• Side mounted input and output jacks
• Powered by standard 9V and 18V centre negative supply (not included)
• Battery operation not supported
• Current draw measured with Truetone 1Spot mA Meter:
• Bypass: Approximately 4 mA
• Engaged (maximum): Approximately 16 mA

Current draw may vary slightly depending on control settings, circuit behaviour, and active features such as gain stages, modulation, filtering, or reverb tails. For best performance, use a high quality isolated power supply that matches the pedal’s current requirements. Always refer to the manufacturer’s recommendations, as incorrect powering may cause damage.

Enclosure Dimensions

• Depth: 118 mm / 4.6 in
• Width: 92 mm / 3.6 in
• Height: 34 mm / 1.3 in

Weight

• 330 g
• 0.73 lbs
